TVI3326A
- ARM Cortex A72 Dual Core, A53 Quad Core CPU, up to 1.8GHz
- Video coding and decoding capabilities, echo suppression
- Supports driver development and customized APP development
- Main parameters
- Application Manual
- Doc Download
-
Product Model
TVI3326A Product Description
Cloud Video Conferencing Terminal Processor
CPU RK3399，SOC Cortex，Dual-core A72 1.8GHz，Quad-core A53 1.5GHz GPU Mali860 650M325M Tri/Sec2600M pixel/sec NPU 3.0 TOPS Operating System
Android 7.1 Memory
LPDDR4 4GB Storage
EMMC 8GB-32GB Network and Connectivity
Wired Network 1*GbE LAN，RJ45 Cellular Network None Wireless Network 1*WIFI，2.4GHz/5GHz NFC None Bluetooth BT4.0 Audio and Video
Display Unit None Speaker None Camera None I/O Interfaces and Display Interfaces
SATA Interface None GPIO 1*GPIO Audio Interface 1* Line_out, 1* Line_In SIM/TF 1*TF Slot， USB Interface 2*USB2.0，1*USB3.0，1*USB Type_C Display Interface 1*VGA_In/DB15 Female, 1*HDMI_Out/Type_A SD Card Interface None Other 1*I2C，1*mini_PCIe +sim Serial/Parallel Port 1*URAT Debug Interface Buttons
1*power button，1*AD_key Power Supply
DC 12V/2A Battery
1*RTC Operating Environment
Operating Temperature: 0~45℃，Relative Humidity: 5%~95% Dimensions
169mmx111mmx29.8mm Weight
593g Certification
CE/3C/RoHs Standard Accessories
1*Adapter
