TVE1086U
- Based on a processor with 4 large A76 cores @ 2.2GHz + 4 small A55 cores @ 2.0GHz
- 10.95-inch IPS display, 1920x1200 resolution
- Supports 90Hz high refresh rate display
- Supports dual-band dual-antenna WIFI 5
- Supports 5G full network access
- Supports magnetic keyboard
- Main parameters
- Application Manual
- Doc Download
-
Product Model
TVE1086U
Product Description
5G Mobile Office Cloud Tablet
Processor
CPU
T760, 4 large cores A76@2.2GHz + 4 small cores A55@2.0GHz
GPU
ARM Mali G57
NPU
3.2 TOPS
Operating System
Android 14
Memory
LPDDR4X 6GB-8GB
Storage
EMMC 128GB-256GB
Network and Connectivity
Wired Network
None
Cellular Network
5G Full Netcom
Wireless Network
WIFI5 2x2, Beidou/GPS
NFC
None
Bluetooth
BT5.0
Audio and Video
Display Unit
10.95 inch, 1920x1200, IPS, 90hz
Speaker
4x BOX large speakers
Camera
Front 5MP, fixed focus, rear 8MP, autofocus, supports flash
I/O and Display Interfaces
SATA Interface
None
GPIO
None
Audio Interface
φ3.5, CTIA mode; 2x microphone input
SIM/TF
1xSIM
USB Interface
1xUSB3.0 TypeC full-function
Display Interface
None
SD Card Interface
None
Other
Magnetic keyboard interface
Serial/Parallel Port
None
Buttons
Power, VOL-, VOL+
Power Supply
20W PD fast charging
Battery
8000mAH/3.8V
Operating Environment
Operating temperature: 0~45℃ Storage temperature: -20~60℃
Dimensions
256.00x167.72x7.95mm
Weight
520g
Certification
CCC, SRRC, CTA
Standard Accessories
Adapter, data cable, card pin
